ETAC ตู้ทดสอบสภาวะแวดล้อม

ตู้ทดสอบสภาวะแวดล้อมและระบบประเมิน Reliability จากประเทศญี่ปุ่น — DKK เป็นตัวแทนจำหน่ายแต่เพียงผู้เดียวในประเทศไทยตั้งแต่ปี 2002

รุ่น	ช่วงอุณหภูมิ	ขนาดภายใน W×H×D (mm)	ความจุ
FX413N-E / FL413N-E	-40 ~ +100°C	600 × 750 × 600	270 L
FX423N-E / FL423N-E	-40 ~ +100°C	700 × 950 × 700	465 L
FX433N-E / FL433N-E	-40 ~ +100°C	1000 × 1000 × 800	800 L
FX713N-E / FL713N-E	-70 ~ +100°C	600 × 750 × 600	270 L
FX723N-E / FL723N-E	-70 ~ +100°C	700 × 950 × 700	465 L
FX733N-E / FL733N-E	-70 ~ +100°C	1000 × 1000 × 800	800 L

รุ่น

ช่วงอุณหภูมิ

ขนาดภายใน W×H×D (mm)

ความจุ

FX413N-E / FL413N-E

-40 ~ +100°C

600 × 750 × 600

270 L

FX423N-E / FL423N-E

-40 ~ +100°C

700 × 950 × 700

465 L

FX433N-E / FL433N-E

-40 ~ +100°C

1000 × 1000 × 800

800 L

FX713N-E / FL713N-E

-70 ~ +100°C

600 × 750 × 600

270 L

FX723N-E / FL723N-E

-70 ~ +100°C

700 × 950 × 700

465 L

FX733N-E / FL733N-E

-70 ~ +100°C

1000 × 1000 × 800

800 L

Specification	FX413N-E	FX423N-E	FX433N-E	FX713N-E	FX723N-E	FX733N-E
สมรรถนะ Performance
Temp. range	-40℃ ~ +100℃【-40℃ ~ +150℃】	-40℃ ~ +100℃【-40℃ ~ +150℃】	-40℃ ~ +100℃【-40℃ ~ +150℃】	-70℃ ~ +100℃【-70℃ ~ +150℃】	-70℃ ~ +100℃【-70℃ ~ +150℃】	-70℃ ~ +100℃【-70℃ ~ +150℃】
Humidity rangeSee catalogue non-frost / humidity control range table.	20% RH ~ 98% RH
Heat up timeFX4: -40℃ to +100℃【+150℃】; FX7: -70℃ to +100℃【+150℃】	Within 45 min【Within 60 min】	Within 50 min【Within 75 min】	Within 45 min【Within 65 min】	Within 55 min【Within 75 min】	Within 70 min【Within 90 min】	Within 50 min【Within 75 min】
Pull down timeFX4: +20℃ to -40℃; FX7: +20℃ to -70℃	Within 40 min	Within 45 min	Within 40 min	Within 90 min	Within 90 min	Within 100 min
Heat up rate	3.5℃/min【3.5℃/min】	3.0℃/min【2.5℃/min】	4.0℃/min【3.5℃/min】	3.0℃/min【3.0℃/min】	2.5℃/min【2.5℃/min】	3.5℃/min【3.0℃/min】
Pull down rate	3.5℃/min【3.5℃/min】	3.0℃/min【3.0℃/min】	3.5℃/min【3.5℃/min】	2.0℃/min【2.0℃/min】	1.7℃/min【1.7℃/min】	1.3℃/min【1.3℃/min】
Temp. & humidity fluctuations	±0.3℃ / ±2.5%RH【±0.5℃ (100.1℃~150℃)】
Temp. & humidity gradient	Temp.: 3.0℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Temp. & humidity variation in space	Temp.: 2.5℃【3.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Ambient temp. range for operationIf installation temp. exceeds approx. +35℃, minimum temp. may not be maintained.	+5℃ ~ +40℃
ตัวเครื่อง Main Unit
Inside dimensions (W × H × D mm)	600 × 750 × 600	700 × 950 × 700	1000 × 1000 × 800	600 × 750 × 600	700 × 950 × 700	1000 × 1000 × 800
Capacity (L)	270	465	800	270	465	800
Outside dimensions (W × H × D mm)	880 × 1653 × 1195	980 × 1853 × 1295	1280 × 1914 × 1395	880 × 1664 × 1195	980 × 1864 × 1295	1280 × 1914 × 1395
Weight (kg)	315	378	543	405	468	633
โครงสร้าง Construction
Exterior material	Steel plate with baked paint finish
Test area material	Stainless steel plate (SUS304)
Air circulator	Sirocco fan
System	DC inverter-controlled air-cooled rotary refrigeration unit	DC inverter-controlled air-cooled rotary refrigeration unit	DC inverter-controlled air-cooled rotary refrigeration unit (×2)	DC inverter + fixed-speed rotary refrigeration unit (dual system)	DC inverter + fixed-speed rotary refrigeration unit (dual system)	DC inverter + fixed-speed rotary refrigeration unit (dual system)
Refrigerant	R-448A	R-448A	R-448A	R-448A + HFC-23	R-448A + HFC-23	R-448A + HFC-23
Heater	Sheathed heater (SUS316L)
HumidifierFX type only.	Nichrome strip heater
Cooler / dehumidifier	Plate fin coil
ระบบควบคุม Controller
Control sensor	JIS C 1604 3-wire resistance temp. detector Pt100
Control method	PID control
Display / resolution	LED indication; 0.1℃ / 1%RH
Setting method (standard)	Main unit setting device / Smart Controller optional web browser system program operation
การเชื่อมต่อ Interface
Memory / Ethernet / USB	8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×2
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply	AC200V 3φ 50/60Hz; voltage fluctuation ±10%
Humidifying water	Ion-exchanged or distilled water (0.1 ~ 10 μS/cm)
Maximum load current (A)	25	25	41	33	35	43
Operating current (A)	20	20	28	20	20	28
Exhaust heat (kW)	0.5 ~ 4.8	0.5 ~ 4.8	0.5 ~ 7.1	0.5 ~ 5.0	0.5 ~ 5.0	0.5 ~ 5.0
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective device	Leakage breaker; motor overload relay; dry-burn protection; pressure/overload/overheat protection; phase detector; heater/control fuses; sensor disconnect; temp/humidity alarms; inverter, outage, filter, wick, and tank alarms
Additional features	Memory backup; temporary stop; monitor; self-diagnosis; power failure recovery; momentary power hold; external alarm; test end/time signal; wait; interlock; auto start/timer; auto light shutoff; manual refrigeration; fault history; continuous status recording; room temp standby
อุปกรณ์มาตรฐาน Standard Equipment
Main unit	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)
Accessories	Instruction manual; φ50mm silicone plug; water tank; wick gauze (12 pcs)

Specification

FX413N-E

FX423N-E

FX433N-E

FX713N-E

FX723N-E

FX733N-E

สมรรถนะ Performance

Temp. range

-40℃ ~ +100℃【-40℃ ~ +150℃】

-70℃ ~ +100℃【-70℃ ~ +150℃】

Humidity rangeSee catalogue non-frost / humidity control range table.

20% RH ~ 98% RH

Heat up timeFX4: -40℃ to +100℃【+150℃】; FX7: -70℃ to +100℃【+150℃】

Within 45 min【Within 60 min】

Within 50 min【Within 75 min】

Within 45 min【Within 65 min】

Within 55 min【Within 75 min】

Within 70 min【Within 90 min】

Within 50 min【Within 75 min】

Pull down timeFX4: +20℃ to -40℃; FX7: +20℃ to -70℃

Within 40 min

Within 45 min

Within 40 min

Within 90 min

Within 100 min

Heat up rate

3.5℃/min【3.5℃/min】

3.0℃/min【2.5℃/min】

4.0℃/min【3.5℃/min】

3.0℃/min【3.0℃/min】

2.5℃/min【2.5℃/min】

3.5℃/min【3.0℃/min】

Pull down rate

3.5℃/min【3.5℃/min】

3.0℃/min【3.0℃/min】

3.5℃/min【3.5℃/min】

2.0℃/min【2.0℃/min】

1.7℃/min【1.7℃/min】

1.3℃/min【1.3℃/min】

Temp. & humidity fluctuations

±0.3℃ / ±2.5%RH【±0.5℃ (100.1℃~150℃)】

Temp. & humidity gradient

Temp.: 3.0℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Temp. & humidity variation in space

Temp.: 2.5℃【3.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Ambient temp. range for operationIf installation temp. exceeds approx. +35℃, minimum temp. may not be maintained.

+5℃ ~ +40℃

ตัวเครื่อง Main Unit

Inside dimensions (W × H × D mm)

600 × 750 × 600

700 × 950 × 700

1000 × 1000 × 800

600 × 750 × 600

700 × 950 × 700

1000 × 1000 × 800

Capacity (L)

270

465

800

270

465

800

Outside dimensions (W × H × D mm)

880 × 1653 × 1195

980 × 1853 × 1295

1280 × 1914 × 1395

880 × 1664 × 1195

980 × 1864 × 1295

1280 × 1914 × 1395

Weight (kg)

315

378

543

405

468

633

โครงสร้าง Construction

Exterior material

Steel plate with baked paint finish

Test area material

Stainless steel plate (SUS304)

Air circulator

Sirocco fan

System

DC inverter-controlled air-cooled rotary refrigeration unit

DC inverter-controlled air-cooled rotary refrigeration unit (×2)

DC inverter + fixed-speed rotary refrigeration unit (dual system)

Refrigerant

R-448A

R-448A + HFC-23

Heater

Sheathed heater (SUS316L)

HumidifierFX type only.

Nichrome strip heater

Cooler / dehumidifier

Plate fin coil

ระบบควบคุม Controller

Control sensor

JIS C 1604 3-wire resistance temp. detector Pt100

Control method

PID control

Display / resolution

LED indication; 0.1℃ / 1%RH

Setting method (standard)

Main unit setting device / Smart Controller optional web browser system program operation

การเชื่อมต่อ Interface

Memory / Ethernet / USB

8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×2

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply

AC200V 3φ 50/60Hz; voltage fluctuation ±10%

Humidifying water

Ion-exchanged or distilled water (0.1 ~ 10 μS/cm)

Maximum load current (A)

Operating current (A)

Exhaust heat (kW)

0.5 ~ 4.8

0.5 ~ 7.1

0.5 ~ 5.0

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective device

Leakage breaker; motor overload relay; dry-burn protection; pressure/overload/overheat protection; phase detector; heater/control fuses; sensor disconnect; temp/humidity alarms; inverter, outage, filter, wick, and tank alarms

Additional features

Memory backup; temporary stop; monitor; self-diagnosis; power failure recovery; momentary power hold; external alarm; test end/time signal; wait; interlock; auto start/timer; auto light shutoff; manual refrigeration; fault history; continuous status recording; room temp standby

อุปกรณ์มาตรฐาน Standard Equipment

Main unit

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)

Accessories

Instruction manual; φ50mm silicone plug; water tank; wick gauze (12 pcs)

Specification	FL413N-E	FL423N-E	FL433N-E	FL713N-E	FL723N-E	FL733N-E
สมรรถนะ Performance
Temp. range	-40℃ ~ +100℃【-40℃ ~ +150℃】	-40℃ ~ +100℃【-40℃ ~ +150℃】	-40℃ ~ +100℃【-40℃ ~ +150℃】	-70℃ ~ +100℃【-70℃ ~ +150℃】	-70℃ ~ +100℃【-70℃ ~ +150℃】	-70℃ ~ +100℃【-70℃ ~ +150℃】
Heat up time	Within 45 min【Within 60 min】	Within 50 min【Within 75 min】	Within 45 min【Within 65 min】	Within 55 min【Within 75 min】	Within 70 min【Within 90 min】	Within 50 min【Within 75 min】
Pull down time	Within 40 min	Within 45 min	Within 40 min	Within 90 min	Within 90 min	Within 100 min
Heat up rate	3.5℃/min【3.5℃/min】	3.0℃/min【2.5℃/min】	4.0℃/min【3.5℃/min】	3.0℃/min【3.0℃/min】	2.5℃/min【2.5℃/min】	3.5℃/min【3.0℃/min】
Pull down rate	3.5℃/min【3.5℃/min】	3.0℃/min【3.0℃/min】	3.5℃/min【3.5℃/min】	2.0℃/min【2.0℃/min】	1.7℃/min【1.7℃/min】	1.3℃/min【1.3℃/min】
Temp. fluctuations	±0.3℃【±0.5℃ (100.1℃~150℃)】
Temp. gradient	3.0℃【5.0℃ (100.1℃~150℃)】
Temp. variation in space	2.5℃【3.0℃ (100.1℃~150℃)】
Ambient temp. range for operationIf installation temp. exceeds approx. +35℃, minimum temp. may not be maintained.	+5℃ ~ +40℃
ตัวเครื่อง Main Unit
Inside dimensions (W × H × D mm)	600 × 750 × 600	700 × 950 × 700	1000 × 1000 × 800	600 × 750 × 600	700 × 950 × 700	1000 × 1000 × 800
Capacity (L)	270	465	800	270	465	800
Outside dimensions (W × H × D mm)	880 × 1653 × 1195	980 × 1853 × 1295	1280 × 1914 × 1395	880 × 1664 × 1195	980 × 1864 × 1295	1280 × 1914 × 1395
Weight (kg)	305	368	533	395	458	623
โครงสร้าง Construction
Exterior material	Steel plate with baked paint finish
Test area material	Stainless steel plate (SUS304)
Air circulator	Sirocco fan
System	DC inverter-controlled air-cooled rotary refrigeration unit	DC inverter-controlled air-cooled rotary refrigeration unit	DC inverter-controlled air-cooled rotary refrigeration unit (×2)	DC inverter + fixed-speed rotary refrigeration unit (dual system)	DC inverter + fixed-speed rotary refrigeration unit (dual system)	DC inverter + fixed-speed rotary refrigeration unit (dual system)
Refrigerant	R-448A	R-448A	R-448A	R-448A + HFC-23	R-448A + HFC-23	R-448A + HFC-23
Heater	Sheathed heater (SUS316L)
Cooler	Plate fin coil
ระบบควบคุม Controller
Control sensor	JIS C 1604 3-wire resistance temp. detector Pt100
Control / display / resolution	PID control; LED indication; 0.1℃ / 1%RH
Setting method (standard)	Main unit setting device / Smart Controller optional web browser system program operation
การเชื่อมต่อ Interface
Memory / Ethernet / USB	8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×2
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply	AC200V 3φ 50/60Hz; voltage fluctuation ±10%
Maximum load current (A)	20	20	33	26	27	35
Operating current (A)	13	13	24	18	18	26
Exhaust heat (kW)	0.5 ~ 4.8	0.5 ~ 4.8	0.5 ~ 7.1	0.5 ~ 5.0	0.5 ~ 5.0	0.5 ~ 5.0
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective device	Leakage breaker; motor overload relay; dry-burn protection; pressure/overload/overheat protection; phase detector; heater/control fuses; sensor disconnect; temp alarms; inverter, outage, filter, wick, and tank alarms
Additional features	Memory backup; temporary stop; monitor; self-diagnosis; power failure recovery; momentary power hold; external alarm; test end/time signal; wait; interlock; auto start/timer; auto light shutoff; manual refrigeration; fault history; continuous status recording; room temp standby
อุปกรณ์มาตรฐาน Standard Equipment
Main unit	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter	Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)
Accessories	Instruction manual; φ50mm silicone plug

Specification

FL413N-E

FL423N-E

FL433N-E

FL713N-E

FL723N-E

FL733N-E

สมรรถนะ Performance

Temp. range

-40℃ ~ +100℃【-40℃ ~ +150℃】

-70℃ ~ +100℃【-70℃ ~ +150℃】

Heat up time

Within 45 min【Within 60 min】

Within 50 min【Within 75 min】

Within 45 min【Within 65 min】

Within 55 min【Within 75 min】

Within 70 min【Within 90 min】

Within 50 min【Within 75 min】

Pull down time

Within 40 min

Within 45 min

Within 40 min

Within 90 min

Within 100 min

Heat up rate

3.5℃/min【3.5℃/min】

3.0℃/min【2.5℃/min】

4.0℃/min【3.5℃/min】

3.0℃/min【3.0℃/min】

2.5℃/min【2.5℃/min】

3.5℃/min【3.0℃/min】

Pull down rate

3.5℃/min【3.5℃/min】

3.0℃/min【3.0℃/min】

3.5℃/min【3.5℃/min】

2.0℃/min【2.0℃/min】

1.7℃/min【1.7℃/min】

1.3℃/min【1.3℃/min】

Temp. fluctuations

±0.3℃【±0.5℃ (100.1℃~150℃)】

Temp. gradient

3.0℃【5.0℃ (100.1℃~150℃)】

Temp. variation in space

2.5℃【3.0℃ (100.1℃~150℃)】

Ambient temp. range for operationIf installation temp. exceeds approx. +35℃, minimum temp. may not be maintained.

+5℃ ~ +40℃

ตัวเครื่อง Main Unit

Inside dimensions (W × H × D mm)

600 × 750 × 600

700 × 950 × 700

1000 × 1000 × 800

600 × 750 × 600

700 × 950 × 700

1000 × 1000 × 800

Capacity (L)

270

465

800

270

465

800

Outside dimensions (W × H × D mm)

880 × 1653 × 1195

980 × 1853 × 1295

1280 × 1914 × 1395

880 × 1664 × 1195

980 × 1864 × 1295

1280 × 1914 × 1395

Weight (kg)

305

368

533

395

458

623

โครงสร้าง Construction

Exterior material

Steel plate with baked paint finish

Test area material

Stainless steel plate (SUS304)

Air circulator

Sirocco fan

System

DC inverter-controlled air-cooled rotary refrigeration unit

DC inverter-controlled air-cooled rotary refrigeration unit (×2)

DC inverter + fixed-speed rotary refrigeration unit (dual system)

Refrigerant

R-448A

R-448A + HFC-23

Heater

Sheathed heater (SUS316L)

Cooler

Plate fin coil

ระบบควบคุม Controller

Control sensor

JIS C 1604 3-wire resistance temp. detector Pt100

Control / display / resolution

PID control; LED indication; 0.1℃ / 1%RH

Setting method (standard)

Main unit setting device / Smart Controller optional web browser system program operation

การเชื่อมต่อ Interface

Memory / Ethernet / USB

8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×2

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply

AC200V 3φ 50/60Hz; voltage fluctuation ±10%

Maximum load current (A)

Operating current (A)

Exhaust heat (kW)

0.5 ~ 4.8

0.5 ~ 7.1

0.5 ~ 5.0

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective device

Leakage breaker; motor overload relay; dry-burn protection; pressure/overload/overheat protection; phase detector; heater/control fuses; sensor disconnect; temp alarms; inverter, outage, filter, wick, and tank alarms

Additional features

อุปกรณ์มาตรฐาน Standard Equipment

Main unit

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter

Ethernet RJ45; φ50mm left cable port; viewing window; interior lighting; casters/adjusters; condenser dust filter (#33 window W420 × H303mm)

Accessories

Instruction manual; φ50mm silicone plug

รุ่น	ช่วงอุณหภูมิ	ขนาดภายใน W×H×D (mm)	ความจุ
FX310 / FL310	-30 ~ +100°C	600 × 750 × 600	270 L
FX320 / FL320	-30 ~ +100°C	700 × 950 × 700	465 L
FX330 / FL330	-30 ~ +100°C	1000 × 1000 × 800	800 L

รุ่น

ช่วงอุณหภูมิ

ขนาดภายใน W×H×D (mm)

ความจุ

FX310 / FL310

-30 ~ +100°C

600 × 750 × 600

270 L

FX320 / FL320

-30 ~ +100°C

700 × 950 × 700

465 L

FX330 / FL330

-30 ~ +100°C

1000 × 1000 × 800

800 L

Specification	FX310	FX320	FX330
สมรรถนะ Performance
Temp. range	-30℃ ~ +100℃【-40℃ ~ +150℃】
Humidity rangeSee catalogue page 2.	20% RH ~ 98% RH
Heat up time-30℃ to +100℃【-30℃ to +150℃】	Within 45 min【Within 60 min】	Within 50 min【Within 75 min】	Within 45 min【Within 65 min】
Pull down time+20℃ to -20℃	Within 40 min	Within 35 min	Within 45 min
Heat up rate-17℃ to +87℃【-12℃ to +132℃】	3.5℃/min【3.5℃/min】	3.0℃/min【2.5℃/min】	4.0℃/min【3.5℃/min】
Pull down rate+87℃ to -17℃【+132℃ to -12℃】	2.5℃/min【2.5℃/min】	3.0℃/min【3.0℃/min】	1.0℃/min【1.0℃/min】
Temp. & humidity fluctuations	±0.3℃ / ±2.5%RH【±0.5℃ (100.1℃~150℃)】
Temp. & humidity gradient	Temp.: 3.0℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Temp. & humidity variation in space	Temp.: 2.5℃【3.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.	+5℃ ~ +40℃
ตัวเครื่อง Main Unit
Inside dimensions (W × H × D mm)	600 × 750 × 600	700 × 950 × 700	1000 × 1000 × 800
Capacity (L)	270	465	800
Outside dimensions (W × H × D mm)	880 × 1653 × 1195	980 × 1853 × 1295	1280 × 1914 × 1395
Weight (kg)	305	380	495
โครงสร้าง Construction
Exterior material	Steel plate with baked paint finish
Test area material	Stainless steel plate (SUS304)
Air circulator	Sirocco fan
System	Air-cooled rotary refrigeration unit
Refrigerant	R-448A
Heater	Nichrome strip heater
Humidifier	Sheathed heater (SUS316L)
Cooler / dehumidifier	Plate fin coil
ระบบควบคุม Controller
Control sensor	JIS C 1604 3-wire resistance temp. detector Pt100
Control / display / resolution	PID control; LED indication; 0.1℃ / 1%RH
Setting method standard	Main unit setting device; constant/program operation up to 9 programs × 26 steps; upper/lower temp/humidity alarms; operation status monitoring
Setting method optional	Smart Connect / Smart Controller; up to 99 programs × 50 steps; repeat up to 999 times
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply	AC200V 3φ 50/60Hz; voltage fluctuation ±10%
Humidifying water	Ion-exchanged or distilled water (0.1 ~ 10 μS/cm)
Maximum load current (A)	24	29	32
Operating current (A)	20	20	22
Exhaust heat (kW)	3.3 ~ 3.8	3.4 ~ 4.9	3.3 ~ 3.8
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective device	Leakage breaker; fan motor overload; dry-burn protection; refrigeration pressure/overload/overheat; phase detector; heater/control fuses; sensor disconnect; temp/humidity alarms; outage/filter/wick/tank alarms
Additional features	Memory backup; humidification delay; room temperature standby; test end output; wait; time signal; hold; temporary stop; status display; power failure protection; self-diagnosis; auto start/timer
อุปกรณ์มาตรฐาน Standard Equipment
Main unit	Round cable port φ50mm left side; casters/adjusters; condenser dust filter
AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.	Instruction manual; φ50mm silicone plug; water tank (#13/#23: 10L ×1, #33: 10L ×2); wick gauze (12 pcs)

Specification

FX310

FX320

FX330

สมรรถนะ Performance

Temp. range

-30℃ ~ +100℃【-40℃ ~ +150℃】

Humidity rangeSee catalogue page 2.

20% RH ~ 98% RH

Heat up time-30℃ to +100℃【-30℃ to +150℃】

Within 45 min【Within 60 min】

Within 50 min【Within 75 min】

Within 45 min【Within 65 min】

Pull down time+20℃ to -20℃

Within 40 min

Within 35 min

Within 45 min

Heat up rate-17℃ to +87℃【-12℃ to +132℃】

3.5℃/min【3.5℃/min】

3.0℃/min【2.5℃/min】

4.0℃/min【3.5℃/min】

Pull down rate+87℃ to -17℃【+132℃ to -12℃】

2.5℃/min【2.5℃/min】

3.0℃/min【3.0℃/min】

1.0℃/min【1.0℃/min】

Temp. & humidity fluctuations

±0.3℃ / ±2.5%RH【±0.5℃ (100.1℃~150℃)】

Temp. & humidity gradient

Temp.: 3.0℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Temp. & humidity variation in space

Temp.: 2.5℃【3.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.

+5℃ ~ +40℃

ตัวเครื่อง Main Unit

Inside dimensions (W × H × D mm)

600 × 750 × 600

700 × 950 × 700

1000 × 1000 × 800

Capacity (L)

270

465

800

Outside dimensions (W × H × D mm)

880 × 1653 × 1195

980 × 1853 × 1295

1280 × 1914 × 1395

Weight (kg)

305

380

495

โครงสร้าง Construction

Exterior material

Steel plate with baked paint finish

Test area material

Stainless steel plate (SUS304)

Air circulator

Sirocco fan

System

Air-cooled rotary refrigeration unit

Refrigerant

R-448A

Heater

Nichrome strip heater

Humidifier

Sheathed heater (SUS316L)

Cooler / dehumidifier

Plate fin coil

ระบบควบคุม Controller

Control sensor

JIS C 1604 3-wire resistance temp. detector Pt100

Control / display / resolution

PID control; LED indication; 0.1℃ / 1%RH

Setting method standard

Main unit setting device; constant/program operation up to 9 programs × 26 steps; upper/lower temp/humidity alarms; operation status monitoring

Setting method optional

Smart Connect / Smart Controller; up to 99 programs × 50 steps; repeat up to 999 times

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply

AC200V 3φ 50/60Hz; voltage fluctuation ±10%

Humidifying water

Ion-exchanged or distilled water (0.1 ~ 10 μS/cm)

Maximum load current (A)

Operating current (A)

Exhaust heat (kW)

3.3 ~ 3.8

3.4 ~ 4.9

3.3 ~ 3.8

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective device

Leakage breaker; fan motor overload; dry-burn protection; refrigeration pressure/overload/overheat; phase detector; heater/control fuses; sensor disconnect; temp/humidity alarms; outage/filter/wick/tank alarms

Additional features

Memory backup; humidification delay; room temperature standby; test end output; wait; time signal; hold; temporary stop; status display; power failure protection; self-diagnosis; auto start/timer

อุปกรณ์มาตรฐาน Standard Equipment

Main unit

Round cable port φ50mm left side; casters/adjusters; condenser dust filter

AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.

Instruction manual; φ50mm silicone plug; water tank (#13/#23: 10L ×1, #33: 10L ×2); wick gauze (12 pcs)

Specification	FL310	FL320	FL330
สมรรถนะ Performance
Temp. range	-30℃ ~ +100℃【-30℃ ~ +150℃】
Heat up time-30℃ to +100℃【-30℃ to +150℃】	Within 45 min【Within 60 min】	Within 50 min【Within 75 min】	Within 45 min【Within 65 min】
Pull down time+20℃ to -20℃	Within 40 min	Within 35 min	Within 45 min
Heat up rate-17℃ to +87℃【-12℃ to +132℃】	3.5℃/min【3.5℃/min】	3.0℃/min【2.5℃/min】	4.0℃/min【3.5℃/min】
Pull down rate+87℃ to -17℃【+132℃ to -12℃】	2.5℃/min【2.5℃/min】	3.0℃/min【3.0℃/min】	1.0℃/min【1.0℃/min】
Temp. fluctuations	±0.3℃【±0.5℃ (100.1℃~150℃)】
Temp. gradient	Temp.: 3.0℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Temp. variation in space	Temp.: 2.5℃【3.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.	+5℃ ~ +40℃
ตัวเครื่อง Main Unit
Inside dimensions (W × H × D mm)	600 × 750 × 600	700 × 950 × 700	1000 × 1000 × 800
Capacity (L)	270	465	800
Outside dimensions (W × H × D mm)	880 × 1653 × 1195	980 × 1853 × 1295	1280 × 1914 × 1395
Weight (kg)	295	370	485
โครงสร้าง Construction
Exterior material	Steel plate with baked paint finish
Test area material	Stainless steel plate (SUS304)
Air circulator	Sirocco fan
System	Air-cooled rotary refrigeration unit
Refrigerant	R-448A
Heater	Nichrome strip heater
Cooler / dehumidifier	Plate fin coil
ระบบควบคุม Controller
Control sensor	JIS C 1604 3-wire resistance temp. detector Pt100
Control / display / resolution	PID control; LED indication; 0.1℃ / 1%RH
Setting method standard	Main unit setting device; constant/program operation up to 9 programs × 26 steps; upper/lower temp/humidity alarms; operation status monitoring	Same as FX310	Same as FX310
Setting method optional	Smart Connect / Smart Controller; up to 99 programs × 50 steps; repeat up to 999 times	Same as FX310	Same as FX310
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply	AC200V 3φ 50/60Hz; voltage fluctuation ±10%
Maximum load current (A)	19	24	30
Operating current (A)	13	13	19
Exhaust heat (kW)	3.3 ~ 3.8	3.4 ~ 4.9	3.3 ~ 3.8
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective device	Leakage breaker; fan motor overload; dry-burn protection; refrigeration pressure/overload/overheat; phase detector; heater/control fuses; sensor disconnect; temp/humidity alarms; outage/filter/wick/tank alarms	Same as FX310	Same as FX310
Additional features	Memory backup; humidification delay; room temperature standby; test end output; wait; time signal; hold; temporary stop; status display; power failure protection; self-diagnosis; auto start/timer	Same as FX310	Same as FX310
อุปกรณ์มาตรฐาน Standard Equipment
Main unit	Round cable port φ50mm left side; casters/adjusters; condenser dust filter	Same as FX310	Same as FX310
AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.	Instruction manual; φ50mm silicone plug

Specification

FL310

FL320

FL330

สมรรถนะ Performance

Temp. range

-30℃ ~ +100℃【-30℃ ~ +150℃】

Heat up time-30℃ to +100℃【-30℃ to +150℃】

Within 45 min【Within 60 min】

Within 50 min【Within 75 min】

Within 45 min【Within 65 min】

Pull down time+20℃ to -20℃

Within 40 min

Within 35 min

Within 45 min

Heat up rate-17℃ to +87℃【-12℃ to +132℃】

3.5℃/min【3.5℃/min】

3.0℃/min【2.5℃/min】

4.0℃/min【3.5℃/min】

Pull down rate+87℃ to -17℃【+132℃ to -12℃】

2.5℃/min【2.5℃/min】

3.0℃/min【3.0℃/min】

1.0℃/min【1.0℃/min】

Temp. fluctuations

±0.3℃【±0.5℃ (100.1℃~150℃)】

Temp. gradient

Temp.: 3.0℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Temp. variation in space

Temp.: 2.5℃【3.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.

+5℃ ~ +40℃

ตัวเครื่อง Main Unit

Inside dimensions (W × H × D mm)

600 × 750 × 600

700 × 950 × 700

1000 × 1000 × 800

Capacity (L)

270

465

800

Outside dimensions (W × H × D mm)

880 × 1653 × 1195

980 × 1853 × 1295

1280 × 1914 × 1395

Weight (kg)

295

370

485

โครงสร้าง Construction

Exterior material

Steel plate with baked paint finish

Test area material

Stainless steel plate (SUS304)

Air circulator

Sirocco fan

System

Air-cooled rotary refrigeration unit

Refrigerant

R-448A

Heater

Nichrome strip heater

Cooler / dehumidifier

Plate fin coil

ระบบควบคุม Controller

Control sensor

JIS C 1604 3-wire resistance temp. detector Pt100

Control / display / resolution

PID control; LED indication; 0.1℃ / 1%RH

Setting method standard

Main unit setting device; constant/program operation up to 9 programs × 26 steps; upper/lower temp/humidity alarms; operation status monitoring

Same as FX310

Setting method optional

Smart Connect / Smart Controller; up to 99 programs × 50 steps; repeat up to 999 times

Same as FX310

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply

AC200V 3φ 50/60Hz; voltage fluctuation ±10%

Maximum load current (A)

Operating current (A)

Exhaust heat (kW)

3.3 ~ 3.8

3.4 ~ 4.9

3.3 ~ 3.8

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective device

Same as FX310

Additional features

Memory backup; humidification delay; room temperature standby; test end output; wait; time signal; hold; temporary stop; status display; power failure protection; self-diagnosis; auto start/timer

Same as FX310

อุปกรณ์มาตรฐาน Standard Equipment

Main unit

Round cable port φ50mm left side; casters/adjusters; condenser dust filter

Same as FX310

AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.

Instruction manual; φ50mm silicone plug

รุ่น	ช่วงอุณหภูมิ	ขนาดภายใน W×H×D (mm)	ความจุ
SXN401-E / SLN401-E	-40 ~ +100°C	500 × 350 × 350	61 L
SXN402-E / SLN402-E	-40 ~ +100°C	(500 × 350 × 350) × 2	61 L × 2
SXN403-E / SLN403-E	-40 ~ +100°C	(500 × 350 × 350) × 3	61 L × 3
SXN412-E / SLN412-E	-40 ~ +100°C	(600 × 600 × 500) × 2	180 L × 2

รุ่น

ช่วงอุณหภูมิ

ขนาดภายใน W×H×D (mm)

ความจุ

SXN401-E / SLN401-E

-40 ~ +100°C

500 × 350 × 350

61 L

SXN402-E / SLN402-E

-40 ~ +100°C

(500 × 350 × 350) × 2

61 L × 2

SXN403-E / SLN403-E

-40 ~ +100°C

(500 × 350 × 350) × 3

61 L × 3

SXN412-E / SLN412-E

-40 ~ +100°C

(600 × 600 × 500) × 2

180 L × 2

Specification	SXN401-E	SXN402-E	SXN403-E	SXN412-E
สมรรถนะ Performance
Temp. range	-40℃ ~ +100℃【-40℃ ~ +150℃】
Humidity rangeSee catalogue page 3 non-frost range.	20% RH ~ 98% RH
Heat up time-40℃ to +100℃【-40℃ to +150℃】	Within 35 min【Within 45 min】	Within 35 min【Within 45 min】	Within 35 min【Within 45 min】	Within 35 min【Within 50 min】
Pull down time+20℃ to -40℃	Within 55 min	Within 55 min	Within 55 min	Within 50 min
Heat up rate-26℃ to +86℃【-21℃ to +131℃】	4.0℃/min【4.0℃/min】	4.0℃/min【4.0℃/min】	4.0℃/min【4.0℃/min】	3.0℃/min【3.0℃/min】
Pull down rate+86℃ to -26℃【+131℃ to -21℃】	2.5℃/min【2.5℃/min】	2.5℃/min【2.5℃/min】	2.5℃/min【2.5℃/min】	3.0℃/min【3.0℃/min】
Temp. & humidity fluctuations	±0.3℃ / ±2.5%RH【±0.5℃ (100.1℃~150℃)】
Temp. & humidity gradient	Temp.: 3.0℃【5.0℃】; Temp./humidity: 2.0℃ / 5.0%RH
Temp. & humidity variation in space	Temp.: 2.5℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.	+5℃ ~ +40℃
ตัวเครื่อง Main Unit
Inside dimensions (W × H × D mm)	500 × 350 × 350	(500 × 350 × 350) × 2	(500 × 350 × 350) × 3	(600 × 600 × 500) × 2
Capacity (L)	61	61 × 2	61 × 3	180 × 2
Outside dimensions (W × H × D mm)	660 × 1285 × 1040	660 × 1885 × 1040	660 × 1955 × 1375	760 × 1855 × 1645
Weight (kg)	190	330	500	475
โครงสร้าง Construction
Exterior / interior / fan	Steel plate baked paint; SUS304; Sirocco fan
System / refrigerant	DC inverter-controlled air-cooled rotary refrigeration unit; R-448A
Heater / humidifier / cooler	Nichrome strip heater; Sheathed heater (SUS316L); Plate fin coil
ระบบควบคุม Controller
Control sensor / method / display	Pt100; PID control; LED indication; 0.1℃ / 1%RH
การเชื่อมต่อ Interface
Memory / Ethernet / USB	8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×1
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply	AC200V 3φ 50/60Hz; voltage fluctuation ±10%
Humidifying water	Ion-exchanged or distilled water (0.1 ~ 10 μS/cm)
Maximum load current (A)	15	30	45	46
Operating current (A)	11	22	33	34
Exhaust heat (kW)	0.62 ~ 3.6	1.24 ~ 7.2	1.86 ~ 10.8	1.0 ~ 9.6
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective device	Leakage breaker; fan motor overload; dry-burn; refrigeration pressure/overload/overheat; phase detector; fuses; sensor disconnect; temp/humidity alarms; inverter/outage/filter/wick/tank alarms
Additional features	Memory backup; temporary stop; monitor; self-diagnosis; power failure protection; external alarm; test end/time signal; wait; interlock; auto start/timer; auto light shutoff; manual refrigeration; fault history; continuous recording; room temp standby
อุปกรณ์มาตรฐาน Standard Equipment
Main unit	Ethernet RJ45; square cable port 100 × 30mm left/right; interior lighting; casters/adjusters; condenser dust filter
AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.	Instruction manual; φ50mm silicone plug; water tank (401/402: 10L ×1, 403/412: 20L ×2); wick gauze (12 pcs/layer)

Specification

SXN401-E

SXN402-E

SXN403-E

SXN412-E

สมรรถนะ Performance

Temp. range

-40℃ ~ +100℃【-40℃ ~ +150℃】

Humidity rangeSee catalogue page 3 non-frost range.

20% RH ~ 98% RH

Heat up time-40℃ to +100℃【-40℃ to +150℃】

Within 35 min【Within 45 min】

Within 35 min【Within 50 min】

Pull down time+20℃ to -40℃

Within 55 min

Within 50 min

Heat up rate-26℃ to +86℃【-21℃ to +131℃】

4.0℃/min【4.0℃/min】

3.0℃/min【3.0℃/min】

Pull down rate+86℃ to -26℃【+131℃ to -21℃】

2.5℃/min【2.5℃/min】

3.0℃/min【3.0℃/min】

Temp. & humidity fluctuations

±0.3℃ / ±2.5%RH【±0.5℃ (100.1℃~150℃)】

Temp. & humidity gradient

Temp.: 3.0℃【5.0℃】; Temp./humidity: 2.0℃ / 5.0%RH

Temp. & humidity variation in space

Temp.: 2.5℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.

+5℃ ~ +40℃

ตัวเครื่อง Main Unit

Inside dimensions (W × H × D mm)

500 × 350 × 350

(500 × 350 × 350) × 2

(500 × 350 × 350) × 3

(600 × 600 × 500) × 2

Capacity (L)

61 × 2

61 × 3

180 × 2

Outside dimensions (W × H × D mm)

660 × 1285 × 1040

660 × 1885 × 1040

660 × 1955 × 1375

760 × 1855 × 1645

Weight (kg)

190

330

500

475

โครงสร้าง Construction

Exterior / interior / fan

Steel plate baked paint; SUS304; Sirocco fan

System / refrigerant

DC inverter-controlled air-cooled rotary refrigeration unit; R-448A

Heater / humidifier / cooler

Nichrome strip heater; Sheathed heater (SUS316L); Plate fin coil

ระบบควบคุม Controller

Control sensor / method / display

Pt100; PID control; LED indication; 0.1℃ / 1%RH

การเชื่อมต่อ Interface

Memory / Ethernet / USB

8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×1

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply

AC200V 3φ 50/60Hz; voltage fluctuation ±10%

Humidifying water

Ion-exchanged or distilled water (0.1 ~ 10 μS/cm)

Maximum load current (A)

Operating current (A)

Exhaust heat (kW)

0.62 ~ 3.6

1.24 ~ 7.2

1.86 ~ 10.8

1.0 ~ 9.6

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective device

Leakage breaker; fan motor overload; dry-burn; refrigeration pressure/overload/overheat; phase detector; fuses; sensor disconnect; temp/humidity alarms; inverter/outage/filter/wick/tank alarms

Additional features

Memory backup; temporary stop; monitor; self-diagnosis; power failure protection; external alarm; test end/time signal; wait; interlock; auto start/timer; auto light shutoff; manual refrigeration; fault history; continuous recording; room temp standby

อุปกรณ์มาตรฐาน Standard Equipment

Main unit

Ethernet RJ45; square cable port 100 × 30mm left/right; interior lighting; casters/adjusters; condenser dust filter

AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.

Instruction manual; φ50mm silicone plug; water tank (401/402: 10L ×1, 403/412: 20L ×2); wick gauze (12 pcs/layer)

Specification	SLN401-E	SLN402-E	SLN403-E	SLN412-E
สมรรถนะ Performance
Temp. range	-40℃ ~ +100℃
Heat up time-40℃ to +100℃【-40℃ to +150℃】	Within 35 min【Within 45 min】	Within 35 min【Within 45 min】	Within 35 min【Within 45 min】	Within 35 min【Within 50 min】
Pull down time+20℃ to -40℃	Within 55 min	Within 55 min	Within 55 min	Within 50 min
Heat up rate-26℃ to +86℃【-21℃ to +131℃】	4.0℃/min【4.0℃/min】	4.0℃/min【4.0℃/min】	4.0℃/min【4.0℃/min】	3.0℃/min【3.0℃/min】
Pull down rate+86℃ to -26℃【+131℃ to -21℃】	2.5℃/min【2.5℃/min】	2.5℃/min【2.5℃/min】	2.5℃/min【2.5℃/min】	3.0℃/min【3.0℃/min】
Temp. fluctuations	±0.3℃
Temp. gradient	Temp.: 3.0℃【5.0℃】; Temp./humidity: 2.0℃ / 5.0%RH
Temp. variation in space	Temp.: 2.5℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH
Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.	+5℃ ~ +40℃
ตัวเครื่อง Main Unit
Inside dimensions (W × H × D mm)	500 × 350 × 350	(500 × 350 × 350) × 2	(500 × 350 × 350) × 3	(600 × 600 × 500) × 2
Capacity (L)	61	61 × 2	61 × 3	180 × 2
Outside dimensions (W × H × D mm)	660 × 1285 × 1040	660 × 1885 × 1040	660 × 1955 × 1375	760 × 1855 × 1645
Weight (kg)	190	330	500	475
โครงสร้าง Construction
Exterior / interior / fan	Steel plate baked paint; SUS304; Sirocco fan
System / refrigerant	DC inverter-controlled air-cooled rotary refrigeration unit; R-448A
Heater / cooler	Nichrome strip heater; Plate fin coil
ระบบควบคุม Controller
Control sensor / method / display	Pt100; PID control; LED indication; 0.1℃ / 1%RH
การเชื่อมต่อ Interface
Memory / Ethernet / USB	8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×1
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply	AC200V 3φ 50/60Hz; voltage fluctuation ±10%
Maximum load current (A)	9	18	27	32
Operating current (A)	7	14	21	26
Exhaust heat (kW)	0.62 ~ 3.6	1.24 ~ 7.2	1.86 ~ 10.8	1.0 ~ 9.6
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective device	Leakage breaker; fan motor overload; dry-burn; refrigeration pressure/overload/overheat; phase detector; fuses; sensor disconnect; temp/humidity alarms; inverter/outage/filter/wick/tank alarms
Additional features	Memory backup; temporary stop; monitor; self-diagnosis; power failure protection; external alarm; test end/time signal; wait; interlock; auto start/timer; auto light shutoff; manual refrigeration; fault history; continuous recording; room temp standby
อุปกรณ์มาตรฐาน Standard Equipment
Main unit	Ethernet RJ45; square cable port 100 × 30mm left/right; interior lighting; casters/adjusters; condenser dust filter
AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.	Instruction manual; φ50mm silicone plug

Specification

SLN401-E

SLN402-E

SLN403-E

SLN412-E

สมรรถนะ Performance

Temp. range

-40℃ ~ +100℃

Heat up time-40℃ to +100℃【-40℃ to +150℃】

Within 35 min【Within 45 min】

Within 35 min【Within 50 min】

Pull down time+20℃ to -40℃

Within 55 min

Within 50 min

Heat up rate-26℃ to +86℃【-21℃ to +131℃】

4.0℃/min【4.0℃/min】

3.0℃/min【3.0℃/min】

Pull down rate+86℃ to -26℃【+131℃ to -21℃】

2.5℃/min【2.5℃/min】

3.0℃/min【3.0℃/min】

Temp. fluctuations

±0.3℃

Temp. gradient

Temp.: 3.0℃【5.0℃】; Temp./humidity: 2.0℃ / 5.0%RH

Temp. variation in space

Temp.: 2.5℃【5.0℃】; Temp./humidity: 1.5℃ / 5.0%RH

Ambient temp. rangeMinimum temp. may not be maintained above approx. +35℃.

+5℃ ~ +40℃

ตัวเครื่อง Main Unit

Inside dimensions (W × H × D mm)

500 × 350 × 350

(500 × 350 × 350) × 2

(500 × 350 × 350) × 3

(600 × 600 × 500) × 2

Capacity (L)

61 × 2

61 × 3

180 × 2

Outside dimensions (W × H × D mm)

660 × 1285 × 1040

660 × 1885 × 1040

660 × 1955 × 1375

760 × 1855 × 1645

Weight (kg)

190

330

500

475

โครงสร้าง Construction

Exterior / interior / fan

Steel plate baked paint; SUS304; Sirocco fan

System / refrigerant

DC inverter-controlled air-cooled rotary refrigeration unit; R-448A

Heater / cooler

Nichrome strip heater; Plate fin coil

ระบบควบคุม Controller

Control sensor / method / display

Pt100; PID control; LED indication; 0.1℃ / 1%RH

การเชื่อมต่อ Interface

Memory / Ethernet / USB

8GB; RJ45 10BASE-T/100BASE-TX ×1; USB2.0 Type A ×1

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply

AC200V 3φ 50/60Hz; voltage fluctuation ±10%

Maximum load current (A)

Operating current (A)

Exhaust heat (kW)

0.62 ~ 3.6

1.24 ~ 7.2

1.86 ~ 10.8

1.0 ~ 9.6

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective device

Leakage breaker; fan motor overload; dry-burn; refrigeration pressure/overload/overheat; phase detector; fuses; sensor disconnect; temp/humidity alarms; inverter/outage/filter/wick/tank alarms

Additional features

อุปกรณ์มาตรฐาน Standard Equipment

Main unit

Ethernet RJ45; square cable port 100 × 30mm left/right; interior lighting; casters/adjusters; condenser dust filter

AccessoriesPerformance stated at ambient +23°C, rated voltage, no specimen unless noted.

Instruction manual; φ50mm silicone plug

รูปสินค้า (รอไฟล์)

Thermal Shock Chamber

WINTECH NEO

เครื่องทดสอบ Thermal shock / Temperature cycle ประสิทธิภาพสูง มีทั้งแบบ Air-tank และ Liquid-tank

จอสัมผัสสี 7.5 นิ้ว แสดงกราฟความคืบหน้าและบันทึกข้อมูลอุณหภูมิอัตโนมัติ
รองรับการทดสอบแบบ 2-zone และ 3-zone
รุ่นสเปก 300°C มีฟังก์ชันลดเวลา recovery ด้านอุณหภูมิต่ำ
Liquid series: เติม brine อัตโนมัติ และใช้กระบอกลมเคลื่อนย้ายชิ้นงานอย่างนุ่มนวล

สรุปรุ่นในซีรีส์

รุ่น	ด้านเย็น	ด้านร้อน	ห้องทดสอบ / ตะกร้า (mm)	ความจุ
NT551A	-65 ~ 0°C	+60 ~ +200°C	370 × 330 × 400	48 L
NT1051A	-65 ~ 0°C	+60 ~ +200°C	370 × 500 × 400	74 L
NT1251A	-65 ~ 0°C	+60 ~ +200°C	650 × 500 × 400	130 L
NT1051W	-80 ~ 0°C	+60 ~ +200°C	370 × 500 × 400	74 L
NT1251W	-80 ~ 0°C	+60 ~ +200°C	650 × 500 × 400	130 L
NT2051W	-80 ~ 0°C	+60 ~ +200°C	700 × 500 × 600	210 L
NT3702A / NT3702W	-65 ~ -10°C	+80 ~ +300°C	370 × 450 × 400	66 L
LT20W (Liquid)	-65 ~ 0°C	+50 ~ +200°C	120 × 120 × 150	2 kg
LT60W (Liquid)	-65 ~ 0°C	+50 ~ +200°C	170 × 170 × 250	3 kg
LT80W (Liquid)	-65 ~ 0°C	+50 ~ +200°C	220 × 220 × 310	6 kg

A = ระบายความร้อนด้วยอากาศ · W = ระบายความร้อนด้วยน้ำ · สารทำความเย็น R-448A

สอบถามรุ่นนี้ Spec Sheet ข้อมูลจากผู้ผลิต ↗

Spec Sheet ตารางสเปกฉบับเต็ม8 รุ่น

Specification	NT551A	NT1051A	NT1251A	NT1051W	NT1251W	NT2051W	NT3702A	NT3702W
ระบบ System
System	2 or 3 zone damper switching
สมรรถนะ Performance
Low temp. exposure range	-65℃ ~ 0℃	-65℃ ~ 0℃	-65℃ ~ 0℃	-65℃ ~ 0℃	-65℃ ~ 0℃	-65℃ ~ 0℃	-65℃ ~ -10℃	-65℃ ~ -10℃
High temp. exposure range	+60℃ ~ +200℃	+60℃ ~ +200℃	+60℃ ~ +200℃	+60℃ ~ +200℃	+60℃ ~ +200℃	+60℃ ~ +200℃	+80℃ ~ +300℃	+80℃ ~ +300℃
Temp. recovery time	Within 5 min	Within 4 min	Within 4 min	Within 4 min	Within 4 min	Within 4 min	Within 10 min (SR ON)	Within 7 min (SR ON)
Low temp. exposure temp./time	-40℃/30min	-55℃/30min	-55℃/30min	-65℃/30min	-65℃/30min	-65℃/30min	-40℃/30min	-40℃/30min
Ambient temp. exposure time	-	5 min	5 min	5 min	5 min	5 min	0 min	0 min
High temp. exposure temp./time	125℃/30min	150℃/30min	150℃/30min	150℃/30min	150℃/30min	150℃/30min	250℃/30min	300℃/30min
Specimen	Plastic mold IC 2.5kg + basket/support 1kg	Plastic mold IC 2.5kg + basket/support 2kg	Plastic mold IC 2.5kg + basket/support 2.8kg	Plastic mold IC 2.5kg + basket/support 1kg	Plastic mold IC 5kg + basket/support 2kg	Plastic mold IC 5kg + basket/support 2.8kg	Aluminium fragment 1.25kg	Aluminium fragment 2.5kg
Sensor position / guarantee ambient	Upwind; 23℃±5℃
Allowable ambient conditions	+10℃ ~ +35℃	+10℃ ~ +32℃	+10℃ ~ +32℃	+5℃ ~ +35℃	+5℃ ~ +35℃	+5℃ ~ +35℃	+10℃ ~ +35℃	+5℃ ~ +35℃
ห้องพรีฮีต / พรีคูล Rooms
Pre-cooling / pre-heating ranges	-75℃ ~ 0℃; +60℃ ~ +225℃	-75℃ ~ 0℃; +60℃ ~ +225℃	-75℃ ~ 0℃; +60℃ ~ +225℃	-80℃ ~ 0℃; +60℃ ~ +225℃	-80℃ ~ 0℃; +60℃ ~ +225℃	-80℃ ~ 0℃; +60℃ ~ +225℃	-75℃ ~ -20℃; +90℃ ~ +350℃	-75℃ ~ -20℃; +90℃ ~ +350℃
ตัวเครื่อง Main Unit
StructureTest room, pre-heating room, pre-cooling room.	3 chambers
Test room inside dimensions (W × H × D mm)	370 × 330 × 400	370 × 500 × 400	650 × 500 × 400	370 × 500 × 400	650 × 500 × 400	700 × 500 × 600	370 × 450 × 400	370 × 450 × 400
Outside dimensions (W × H × D mm)Not including protrusions.	1150 × 1800 × 1325	1150 × 1940 × 1770	1430 × 1940 × 1720	1150 × 1940 × 1620	1430 × 1940 × 1470	1480 × 1940 × 1670	1150 × 1980 × 1720	1150 × 1980 × 1570
Weight (kg)	Approx. 730	Approx. 1050	Approx. 1230	Approx. 1020	Approx. 1180	Approx. 1280	Approx. 1150	Approx. 1000
Test room load capacity	30kg uniformly distributed	100kg uniformly distributed	100kg uniformly distributed	30kg uniformly distributed	100kg uniformly distributed	100kg uniformly distributed	30kg uniformly distributed	30kg uniformly distributed
Specimen baskets / load capacity	6 pcs; 5.0kg/pc	7 pcs; 5.0kg/pc	7 pcs; 5.0kg/pc	7 pcs; 5.0kg/pc	7 pcs; 7.5kg/pc	7 pcs; 7.5kg/pc	6 pcs; 5.0kg/pc	6 pcs; 5.0kg/pc
Door / cable port	Single door; φ50mm round left port	Single door; φ50mm round left port	Single door; φ50mm round left port	Single door; φ50mm round left port	Single door; φ50mm round left port	Single door; φ50mm round left port	Single door; 30×100mm square left port	Single door; 30×100mm square left port
ระบบควบคุม Controller
Controller	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A (with SR function)	PID upwind; ECO operation; LCD touch panel; 7.5 inch color LCD; 1℃; 30 programs; 9999 cycles; 16GB; USB2.0 Type A (with SR function)
Exposure time setting	High/low max 120 min; ambient max 99 min
Additional features	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying; plus SR function	Auto start; automatic defrost; WAIT; self-monitoring; test end display; elapsed cycle; troubleshooting; auto pre-cooling/heating setup; alarm history; end state selection; cycle counter; outputs; alarms; graphic display; USB; pause; pre-cooling drying; plus SR function
อุปกรณ์ Equipment
Temp. sensor / air / damper	Pt100; Sirocco fan; air cylinder
ระบบทำความเย็น Refrigeration
System / compressor / refrigerant	Dual refrigeration; air-cooled hermetic reciprocating; R-448A + R23	Dual refrigeration; air-cooled hermetic scroll; R-448A + R23	Dual refrigeration; air-cooled hermetic scroll; R-448A + R23	Dual refrigeration; water-cooled hermetic scroll; R-448A + R23	Dual refrigeration; water-cooled hermetic scroll; R-448A + R23	Dual refrigeration; water-cooled hermetic scroll; R-448A + R23	Dual refrigeration; scroll compressor; R-404A + R23	Dual refrigeration; scroll compressor; R-404A + R23
อุปกรณ์ Equipment
Heater	Strip wire heater
ระบบสาธารณูปโภค Utility
Power supply	AC200V 3φ 50/60Hz ±10%
Maximum power consumption (kVA)	19	30	32	35	44	48	35	40
Maximum load current (A)	55	87	93	100	125	138	101	113
Operating current (A)	26	49	50	56	63	65	71	80
Refrigeration exhaust heat (kW)	7	11	11	-	-	-	11	-
Cooling water supply rate	-	-	-	38 L/min (25℃) / 55 L/min (32℃); 1¼B	47 L/min (25℃) / 82 L/min (32℃); 1¼B	47 L/min (25℃) / 82 L/min (32℃); 1¼B	-	55 L/min (32℃)
Cooling water supply pressure	-	-	-	0.2 ~ 0.5MPa	0.2 ~ 0.5MPa	0.2 ~ 0.5MPa	-	0.2 ~ 0.5MPa
Dry air / drainage	0.4~0.7MPa dry air; atmospheric drainage φ8×φ11 hose
ความปลอดภัย / อุปกรณ์เสริม Safety / Accessories
Protection device	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock; plus cooling water abnormality/interruption detection	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock; plus cooling water abnormality/interruption detection	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock; plus cooling water abnormality/interruption detection	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock	Earth leakage breaker; blower thermal; reverse phase relay; overheat protectors; temp alarms; refrigeration overload/high-low pressure; damper proximity; door detection; sensor disconnect; ambient abnormality; external alarm; interlock
AccessoriesPerformance at ambient 23℃±5℃ with ECO OFF unless noted.	Cable port silicone plug (2 pcs); instruction manual	Cable port silicone plug (2 pcs); instruction manual	Cable port silicone plug (2 pcs); instruction manual	Cable port silicone plug (2 pcs); instruction manual; Y strainer	Cable port silicone plug (2 pcs); instruction manual	Cable port silicone plug (2 pcs); instruction manual	Cable port silicone plug (2 pcs); instruction manual	Cable port silicone plug (2 pcs); instruction manual

【】 = ค่าเมื่อเลือก Option สเปกอุณหภูมิสูง (+150°C) · ค่าสมรรถนะวัดที่อุณหภูมิห้อง +23°C แรงดันไฟพิกัด และไม่มีชิ้นงาน (ตามแคตตาล็อก) · สเปกอาจเปลี่ยนแปลงโดยผู้ผลิตโดยไม่แจ้งล่วงหน้า

ขอใบเสนอราคารุ่นนี้

รุ่น	ช่วงอุณหภูมิ	ขนาดภายใน W×H×D (mm)	ความจุ
HT210 / HT310	RT+20 ~ 200°C / 300°C	450 × 450 × 450	91 L
HT220 / HT320	RT+20 ~ 200°C / 300°C	600 × 600 × 600	216 L
HT240 / HT340	RT+20 ~ 200°C / 300°C	800 × 1000 × 800	640 L
HT250 / HT350	RT+20 ~ 200°C / 300°C	1000 × 1000 × 800	800 L
HS240 (Vertical)	RT+20 ~ 200°C	600 × 900 × 600	324 L
HS250 (Vertical)	RT+20 ~ 200°C	600 × 1200 × 600	432 L
HS260 (Vertical)	RT+20 ~ 200°C	800 × 1200 × 600	576 L

รุ่น

ช่วงอุณหภูมิ

ขนาดภายใน W×H×D (mm)

ความจุ

HT210 / HT310

RT+20 ~ 200°C / 300°C

450 × 450 × 450

91 L

HT220 / HT320

RT+20 ~ 200°C / 300°C

600 × 600 × 600

216 L

HT240 / HT340

RT+20 ~ 200°C / 300°C

800 × 1000 × 800

640 L

HT250 / HT350

RT+20 ~ 200°C / 300°C

1000 × 1000 × 800

800 L

HS240 (Vertical)

RT+20 ~ 200°C

600 × 900 × 600

324 L

HS250 (Vertical)

RT+20 ~ 200°C

600 × 1200 × 600

432 L

HS260 (Vertical)

RT+20 ~ 200°C

800 × 1200 × 600

576 L

รุ่น	ช่วงอุณหภูมิ	ช่วงความชื้น	ขนาดภายใน W×H×D (mm)	ความจุ
CH111PA-E / CH111P-E	-10 ~ +80°C	20–95%RH	1670 × 2200 × 1670	6.1 m³
CH121PA-E / CH121P-E	-10 ~ +80°C	20–95%RH	3470 × 2200 × 1670	12.7 m³
CH131P-E	-10 ~ +80°C	20–95%RH	3470 × 2200 × 2570	19.6 m³
CH311PA-E / CH311P-E	-30 ~ +80°C	15–95%RH	1670 × 2200 × 1670	6.1 m³
CH321PA-E / CH321P-E	-30 ~ +80°C	15–95%RH	3470 × 2200 × 1670	12.7 m³
CH331P-E	-30 ~ +80°C	15–95%RH	3470 × 2200 × 2570	19.6 m³

รุ่น

ช่วงอุณหภูมิ

ช่วงความชื้น

ขนาดภายใน W×H×D (mm)

ความจุ

CH111PA-E / CH111P-E

-10 ~ +80°C

20–95%RH

1670 × 2200 × 1670

6.1 m³

CH121PA-E / CH121P-E

-10 ~ +80°C

20–95%RH

3470 × 2200 × 1670

12.7 m³

CH131P-E

-10 ~ +80°C

20–95%RH

3470 × 2200 × 2570

19.6 m³

CH311PA-E / CH311P-E

-30 ~ +80°C

15–95%RH

1670 × 2200 × 1670

6.1 m³

CH321PA-E / CH321P-E

-30 ~ +80°C

15–95%RH

3470 × 2200 × 1670

12.7 m³

CH331P-E

-30 ~ +80°C

15–95%RH

3470 × 2200 × 2570

19.6 m³

Specification	CH111P-E	CH121P-E	CH131P-E	CH311P-E	CH321P-E	CH331P-E
สมรรถนะ Performance
Temperature range	-10℃ ~ +80℃	-10℃ ~ +80℃	-10℃ ~ +80℃	-30℃ ~ +80℃	-30℃ ~ +80℃	-30℃ ~ +80℃
Humidity range	20% ~ 95%RH	20% ~ 95%RH	20% ~ 95%RH	15% ~ 95%RH	15% ~ 95%RH	15% ~ 95%RH
Temp. ramp-down rate	0.4℃/min
Temp. ramp-up rate	1℃/min
Temp. humid. variation	±0.5℃ / ±4%RH
Temp. gradient	2.5℃ / 8%RH
Temp. variation in space	2.5℃ / 8%RH
Sensor / operating ambientCooling water temperature 30℃ or less.	Pt100Ω; +5℃ ~ +35℃
ตัวห้อง Main Body
Internal dimensions (W × H × D mm)	1670×2200×1670	3470×2200×1670	3470×2200×2570	1670×2200×1670	3470×2200×1670	3470×2200×2570
Capacity (m³)	6.1	12.7	19.6	6.1	12.7	19.6
Floor area (m²)	2.79	5.79	8.92	2.79	5.79	8.92
External dimensions (W × H × D mm)	2455×2405×1800	4255×2405×1800	4255×2405×2700	2455×2405×1800	4255×2405×1800	4255×2405×2700
Door / floor load	Single hinged door W850×H1820; 600kg/m² surface load
Exterior / interior / insulation	Colored steel plate white gray; SUS304 2B; rigid urethane foam 65mm
อุปกรณ์หลัก Main Equipment
Circulation fan / refrigerator	Sirocco fan; water cooling type ×1 set	Sirocco fan; water cooling type ×2 sets	Sirocco fan; water cooling type ×3 sets	Sirocco fan; water cooling type ×1 set	Sirocco fan; water cooling type ×2 sets	Sirocco fan; water cooling type ×3 sets
Refrigerant / expansion	R-448A; pulse controlled electronic expansion valve
Heaters / cooling coil	Nichrome strip heater; sheathed humidification heater; plate fin coil
Display / communication	7.5 inch color LCD display; RS485 I/F optional
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply / earth leakage breaker	AC200V 3φ 50/60Hz ±10%; 60A	AC200V 3φ 50/60Hz ±10%; 60A	AC200V 3φ 50/60Hz ±10%; 75A	AC200V 3φ 50/60Hz ±10%; 60A	AC200V 3φ 50/60Hz ±10%; 60A	AC200V 3φ 50/60Hz ±10%; 75A
Max. load current (A)	52	61	71	52	61	71
Rated power (kVA)	17	21	23.5	17	21	23.5
Cooling water volume (cooling tons)1 cooling ton = 13 L/min.	2	5	6.9	2	5	6.9
Max. humidification water volume (L/hr)	2
Humidification water / drainage	Pure water 0.1~10 μS/cm, 0.1~0.3MPa, 1/2 pipe; natural drainage 20A ×2
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective / safety device	Earth leakage breaker; overheat prevention; no-water heating prevention; high/low pressure switch; fan thermal; overload relays/breakers; lighting earth leakage; indoor emergency stop; emergency escape
Attached functions	Auto start; wait; self-monitoring; test end time; troubleshooting; alarm history; upper/lower temp/humidity alarms; pause; graphic display; USB history; humidification delay; refrigerator selection; time signal; power failure protection; interlock/external alarm; calendar timer; water monitoring; indicators
อุปกรณ์มาตรฐาน Standard Equipment
Standard equipmentPerformance at ambient +23℃, no specimen/load, cooling water ≤25℃, JTMK09 compliant.	Observation window W350×H350mm; interior light; one round cable port/hole φ54; ventilation fan; refrigerator pressure gauge; wick; water control valve; instruction manual; inspection/certificate with performance data; warranty sheet.

Specification

CH111P-E

CH121P-E

CH131P-E

CH311P-E

CH321P-E

CH331P-E

สมรรถนะ Performance

Temperature range

-10℃ ~ +80℃

-30℃ ~ +80℃

Humidity range

20% ~ 95%RH

15% ~ 95%RH

Temp. ramp-down rate

0.4℃/min

Temp. ramp-up rate

1℃/min

Temp. humid. variation

±0.5℃ / ±4%RH

Temp. gradient

2.5℃ / 8%RH

Temp. variation in space

2.5℃ / 8%RH

Sensor / operating ambientCooling water temperature 30℃ or less.

Pt100Ω; +5℃ ~ +35℃

ตัวห้อง Main Body

Internal dimensions (W × H × D mm)

1670×2200×1670

3470×2200×1670

3470×2200×2570

1670×2200×1670

3470×2200×1670

3470×2200×2570

Capacity (m³)

6.1

12.7

19.6

6.1

12.7

19.6

Floor area (m²)

2.79

5.79

8.92

2.79

5.79

8.92

External dimensions (W × H × D mm)

2455×2405×1800

4255×2405×1800

4255×2405×2700

2455×2405×1800

4255×2405×1800

4255×2405×2700

Door / floor load

Single hinged door W850×H1820; 600kg/m² surface load

Exterior / interior / insulation

Colored steel plate white gray; SUS304 2B; rigid urethane foam 65mm

อุปกรณ์หลัก Main Equipment

Circulation fan / refrigerator

Sirocco fan; water cooling type ×1 set

Sirocco fan; water cooling type ×2 sets

Sirocco fan; water cooling type ×3 sets

Sirocco fan; water cooling type ×1 set

Sirocco fan; water cooling type ×2 sets

Sirocco fan; water cooling type ×3 sets

Refrigerant / expansion

R-448A; pulse controlled electronic expansion valve

Heaters / cooling coil

Nichrome strip heater; sheathed humidification heater; plate fin coil

Display / communication

7.5 inch color LCD display; RS485 I/F optional

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply / earth leakage breaker

AC200V 3φ 50/60Hz ±10%; 60A

AC200V 3φ 50/60Hz ±10%; 75A

AC200V 3φ 50/60Hz ±10%; 60A

AC200V 3φ 50/60Hz ±10%; 75A

Max. load current (A)

Rated power (kVA)

23.5

Cooling water volume (cooling tons)1 cooling ton = 13 L/min.

6.9

Max. humidification water volume (L/hr)

Humidification water / drainage

Pure water 0.1~10 μS/cm, 0.1~0.3MPa, 1/2 pipe; natural drainage 20A ×2

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective / safety device

Earth leakage breaker; overheat prevention; no-water heating prevention; high/low pressure switch; fan thermal; overload relays/breakers; lighting earth leakage; indoor emergency stop; emergency escape

Attached functions

Auto start; wait; self-monitoring; test end time; troubleshooting; alarm history; upper/lower temp/humidity alarms; pause; graphic display; USB history; humidification delay; refrigerator selection; time signal; power failure protection; interlock/external alarm; calendar timer; water monitoring; indicators

อุปกรณ์มาตรฐาน Standard Equipment

Standard equipmentPerformance at ambient +23℃, no specimen/load, cooling water ≤25℃, JTMK09 compliant.

Observation window W350×H350mm; interior light; one round cable port/hole φ54; ventilation fan; refrigerator pressure gauge; wick; water control valve; instruction manual; inspection/certificate with performance data; warranty sheet.

Specification	CH111PA-E	CH121PA-E	CH311PA-E	CH321PA-E
สมรรถนะ Performance
Temperature range	-10℃ ~ +80℃	-10℃ ~ +80℃	-30℃ ~ +80℃	-30℃ ~ +80℃
Humidity range	20% ~ 95%RH	20% ~ 95%RH	15% ~ 95%RH	15% ~ 95%RH
Temp. ramp-down rate	0.4℃/min
Temp. ramp-up rate	1℃/min
Temp. humid. variation	±0.5℃ / ±4%RH
Temp. gradient	2.5℃ / 8%RH
Temp. variation in space	2.5℃ / 8%RH
Sensor / operating ambientCooling water temperature 30℃ or less.	Pt100Ω; +5℃ ~ +30℃
ตัวห้อง Main Body
Internal dimensions (W × H × D mm)	1670×2200×1670	3470×2200×1670	1670×2200×1670	3470×2200×1670
Capacity (m³)	6.1	12.7	6.1	12.7
Floor area (m²)	2.79	5.79	2.79	5.79
External dimensions (W × H × D mm)	2455×2405×1800	4255×2405×1800	2455×2405×1800	4255×2405×1800
Door / floor load	Single hinged door W850×H1820; 600kg/m² surface load
Exterior / interior / insulation	Colored steel plate white gray; SUS304 2B; rigid urethane foam 65mm
อุปกรณ์หลัก Main Equipment
Circulation fan / refrigerator	Sirocco fan; air cooling type ×1 external unit	Sirocco fan; air cooling type ×2 external unit	Sirocco fan; air cooling type ×1 external unit	Sirocco fan; air cooling type ×2 external unit
Refrigerant / expansion	R-448A; pulse controlled electronic expansion valve
Heaters / cooling coil	Nichrome strip heater; sheathed humidification heater; plate fin coil
Display / communication	7.5 inch color LCD display; RS485 I/F optional
ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment
Power supply / earth leakage breaker	AC200V 3φ 50/60Hz ±10%; 60A	AC200V 3φ 50/60Hz ±10%; 75A	AC200V 3φ 50/60Hz ±10%; 60A	AC200V 3φ 50/60Hz ±10%; 75A
Max. load current (A)	53	-	64	-
Rated power (kVA)	18	-	21	-
Cooling water volume (cooling tons)1 cooling ton = 13 L/min.	-
Max. humidification water volume (L/hr)	2
Humidification water / drainage	Pure water 0.1~10 μS/cm, 0.1~0.3MPa, 1/2 pipe; natural drainage 20A ×2
ความปลอดภัย / ฟังก์ชัน Safety / Features
Protective / safety device	Earth leakage breaker; overheat prevention; no-water heating prevention; high/low pressure switch; fan thermal; overload relays/breakers; lighting earth leakage; indoor emergency stop; emergency escape
Attached functions	Auto start; wait; self-monitoring; test end time; troubleshooting; alarm history; upper/lower temp/humidity alarms; pause; graphic display; USB history; humidification delay; refrigerator selection; time signal; power failure protection; interlock/external alarm; calendar timer; water monitoring; indicators
อุปกรณ์มาตรฐาน Standard Equipment
Standard equipmentPerformance at ambient +23℃, no specimen/load, cooling water ≤25℃, JTMK09 compliant.	Observation window W350×H350mm; interior light; one round cable port/hole φ54; ventilation fan; refrigerator pressure gauge; wick; water control valve; instruction manual; inspection/certificate with performance data; warranty sheet.

Specification

CH111PA-E

CH121PA-E

CH311PA-E

CH321PA-E

สมรรถนะ Performance

Temperature range

-10℃ ~ +80℃

-30℃ ~ +80℃

Humidity range

20% ~ 95%RH

15% ~ 95%RH

Temp. ramp-down rate

0.4℃/min

Temp. ramp-up rate

1℃/min

Temp. humid. variation

±0.5℃ / ±4%RH

Temp. gradient

2.5℃ / 8%RH

Temp. variation in space

2.5℃ / 8%RH

Sensor / operating ambientCooling water temperature 30℃ or less.

Pt100Ω; +5℃ ~ +30℃

ตัวห้อง Main Body

Internal dimensions (W × H × D mm)

1670×2200×1670

3470×2200×1670

1670×2200×1670

3470×2200×1670

Capacity (m³)

6.1

12.7

6.1

12.7

Floor area (m²)

2.79

5.79

2.79

5.79

External dimensions (W × H × D mm)

2455×2405×1800

4255×2405×1800

2455×2405×1800

4255×2405×1800

Door / floor load

Single hinged door W850×H1820; 600kg/m² surface load

Exterior / interior / insulation

Colored steel plate white gray; SUS304 2B; rigid urethane foam 65mm

อุปกรณ์หลัก Main Equipment

Circulation fan / refrigerator

Sirocco fan; air cooling type ×1 external unit

Sirocco fan; air cooling type ×2 external unit

Sirocco fan; air cooling type ×1 external unit

Sirocco fan; air cooling type ×2 external unit

Refrigerant / expansion

R-448A; pulse controlled electronic expansion valve

Heaters / cooling coil

Nichrome strip heater; sheathed humidification heater; plate fin coil

Display / communication

7.5 inch color LCD display; RS485 I/F optional

ระบบสาธารณูปโภคที่ต้องใช้ Required Equipment

Power supply / earth leakage breaker

AC200V 3φ 50/60Hz ±10%; 60A

AC200V 3φ 50/60Hz ±10%; 75A

AC200V 3φ 50/60Hz ±10%; 60A

AC200V 3φ 50/60Hz ±10%; 75A

Max. load current (A)

Rated power (kVA)

Cooling water volume (cooling tons)1 cooling ton = 13 L/min.

Max. humidification water volume (L/hr)

Humidification water / drainage

Pure water 0.1~10 μS/cm, 0.1~0.3MPa, 1/2 pipe; natural drainage 20A ×2

ความปลอดภัย / ฟังก์ชัน Safety / Features

Protective / safety device

Attached functions

อุปกรณ์มาตรฐาน Standard Equipment

Standard equipmentPerformance at ambient +23℃, no specimen/load, cooling water ≤25℃, JTMK09 compliant.

รายการ	ค่า
จำนวนช่องวัด	8 – 128 ch
แรงดันสูงสุด	10 kV (HV unit)
ความต้านทานสูงสุดที่วัดได้	10,000 PΩ
รอบการวัด	20 msec / ch
ย่านกระแส	3.2 mA – 320 pA
SMU board	250 V (16 ch / 8 ch) · 500 V · 1 kV

รายการ

ค่า

จำนวนช่องวัด

8 – 128 ch

แรงดันสูงสุด

10 kV (HV unit)

ความต้านทานสูงสุดที่วัดได้

10,000 PΩ

รอบการวัด

20 msec / ch

ย่านกระแส

3.2 mA – 320 pA

SMU board

250 V (16 ch / 8 ch) · 500 V · 1 kV

รายการ	ค่า
จำนวนช่องวัด	32 – 288 ch
ย่านวัด AC	2 mΩ – 2 kΩ
ย่านวัด DC	200 mΩ – 200 kΩ
รอบการวัด	10 ms / 200 ms

รายการ

ค่า

จำนวนช่องวัด

32 – 288 ch

ย่านวัด AC

2 mΩ – 2 kΩ

ย่านวัด DC

200 mΩ – 200 kΩ

รอบการวัด

10 ms / 200 ms

ETAC ตู้ทดสอบสภาวะแวดล้อม

ตู้ทดสอบอุณหภูมิและความชื้น

HIFLEX NEO-E

HIFLEX SC

HIFLEX NEO-ES

เครื่องทดสอบ Thermal shock

WINTECH NEO

ตู้อบอุตสาหกรรม

HISPEC

HISPEC รุ่นเฉพาะงาน

HISPEC HG Type

HISPEC K Type

HISPEC N Type

HISPEC H Type

HISPEC S Type

ห้องทดสอบ Walk-in

COLONIA E Series

ระบบประเมิน Reliability

SIR13

MLR23

รุ่นอื่น ๆ

HIFLEX SBC

DEW CYCLE

LABONIC

TLE60

MCL42

ED71

มีโจทย์การทดสอบ? ให้เราช่วยเลือกรุ่นที่เหมาะสม

สอบถาม / ขอใบเสนอราคา
